FXLS210S.TB-Y70121553,

FXLS310S.TB-Y70121554,

FXLS310S.TB-Y70121552.

Product Description: Terminal and Junction Boxes Ex e / Ex i with Return Flange, Stainless Steel FXLS*.T

Stainless Steel enclosure, Installation in Zone 1, Zone 2, Zone 21 and Zone 22, Ex e, Ex ia and Ex tb certified, 16 enclosure size options, Return Flange Sealing, Customizable configuration of terminals, cable entries and cable gland types as per specification, Up to 3 gland plates, Wide range of accessories available.

Function: FXLS*.T

The FXLS series is a range of terminal boxes that can be equipped with various types and quantities of terminals and cable glands.

The enclosures are manufactured from electropolished AISI 316L stainless steel as standard to provide excellent tarnish and corrosion resistance. This surface finish is ideally suited to meet hygienic requirements valid in pharmaceutical and food processing plants.

All FXLS enclosures feature a return flange sealing method which prevents accumulated dirt, dust and moisture from entering the enclosure when the hinged lid is opened.

Durable materials allows the terminal box to be used in ambient temperatures between -50 °C and +120 °C.
