YOKOGAWA ALR111 and ALR121 Serial Communication Modules for FIO that a field control station (FCS) uses to perform serial communication with subsystems such as FA-M3. These serial communication modules can be mounted on field control units (AFV30, AFV40, AFV10, and AFF50), ESB bus node unit (ANB10), optical ESB bus node unit (ANB11), and ER bus node unit (ANR10).

Hardware Requirements

The serial communication module runs on the following FCS.

 AFV30S, AFV30D, AFV40S, AFV40D, AFV10S, AFV10D,

AFS30S, AFS30D, AFS40S, AFS40D,

AFG30S, AFG30D, AFG40S, AFG40D,

AFG81S, AFG81D, AFG82S, AFG82, AFG83S, AFG83D, AFG84S, AFG84D,

AFF50S, AFF50D

Software Requirements

The serial communication module runs on the control functions of the following FCS.

 LFS1700 Control Function for Field Control Station (for AFV30/AFV40, Vnet/IP and FIO): for AFV30/AFV40

LFS1500 Control Function for Field Control Station (for AFV10, Vnet/IP and FIO): for AFV10

LFS1300 Control Function for Standard Field Control Station (for V net and FIO): for AFS30/AFS40

LFS1330 Control Function for Enhanced Field Control Station (for V net and FIO): for AFG30 AFG40 / AFG8

LFS1350 Control Function for Compact Field Control Station (for V net and FIO): for AFF50

Engineering Requirements

Works on LHS5100/LHMS5100 Standard Builder Function
