The AC500-eCo from ABB is a range of scalable PLCs offering cost effectiveness for modern industrial automation applications where small flexible PLC solutions often represent the ideal solution.

Save money by starting small - the flexibility of the AC500 platform enables to scale up as and when needs dictate.

ABB’s AC500-eCo has been designed to integrate seamlessly into the broader AC500 family, offering you the decisive benefit of having a fully scalable and modular system.

The AC500-eCo offers individually customized solutions to be created by using S500 and S500-eCo I/O modules for small applications.

The Automation Builder engineering suite available across the entire AC500 PLC range will save you time with easy configuration, many libraries and function blocks for the most diverse specific customer requirements.

Our offering: CPUs, S500-eCo I/O modules

AC500-eCo - S500-eCo I/O modules

DI561    8DI    24 V DC

DI562    16DI    24 V DC

DI571    8DI    100-240 V AC

DI572    16DI    100-240 V AC

DO561    8DO    Transistor

DO562    16DO    Transistor

DO571    8DO    Relay

DO572    8DO    Triac

DO573    16DO    Relay

DX561    8DI / 8DO    24 V DC / Transistor

DX571    8DI / 8DO    24 V DC / Relay

DC561    16DC    24 V DC / Transistor, configurable, Interfast

DC562    16DC    24 V DC / Transistor, configurable

AI561    4AI    V, mA

AI562    2AI    RTD

AI563    4AI    Thermocouple

AO561    2AO    V, mA

AX561    4AI / 2AO    V, mA

FM562    4DI 4 pulse outputs    Pulse Train Outputs for 2 axes

AC500-eCo - CPUs

PM554-TP-ETH    8DI 6DO Transistor    24 V DC

PM556-TP-ETH    8DI 6DO Transistor    24 V DC

PM564-TP-ETH    6DI 6DO 2AI 1AO Transistor    24 V DC

PM564-RP-ETH    6DI 6DO 2AI 1AO Relay    24 V DC

PM564-RP-ETH-AC    6DI 6DO 2AI 1AO Relay    100-240 V AC

PM566-TP-ETH    6DI 6DO 2AI 1AO Transistor     24 V DC
