Pepperl+Fuchs Inductive sensor: NJ50-FP-N-P4, NJ20S+U1+N, NJ4-12GK-SN, NCN4-12GM60-B3-C2-V1. Pepperl+Fuchs Switch Amplifier KCD2-SR-Ex1.LB. Pepperl+Fuchs Strain Gauge Converter KFD2-WAC2-Ex1.D.

Pepperl+Fuchs Inductive sensor NJ20S+U1+N

Switching function: Normally closed (NC)

Output type: NAMUR with safety function

Rated operating distance: 20 mm

Installation: non-flush

Usable up to SIL 3 acc. to IEC 61508

Pepperl+Fuchs Inductive sensor NJ50-FP-N-P4

Switching function: Normally closed (NC)

Output type: NAMUR

Rated operating distance: 50 mm

Installation: non-flush

Output type: 2-wire

Pepperl+Fuchs Switch Amplifier KCD2-SR-Ex1.LB

1-channel isolated barrier

24 V DC supply (Power Rail)

Dry contact or NAMUR inputs

Usable as signal splitter (1 input and 2 outputs)

Relay contact output

Fault relay contact output

Line fault detection (LFD)

Housing width 12.5 mm

Up to SIL 2 acc. to IEC 61508

Pepperl+Fuchs Strain Gauge Converter KFD2-WAC2-Ex1.D

1-channel isolated barrier

24 V DC supply (Power Rail)

Strain gauge input (full or half bridge)

Output 0 mA ... ± 20 mA or 0 V ... ± 10 V

2 relay contact outputs

Programmable high/low alarm

Configurable by PACTware or keypad

RS-485 interface

Line fault detection (LFD)
