The Fisher 3582i is a field-proven positioner which is accurate, fast-responding, and able to withstand the vibrations of most plant environments. Low steady-state air consumption contributes to efficient operation.

Features

● The range of the adjustable zero and span permits the use of all standard input signals including split ranges.

● Because units from one positioner family can be used in a variety of control applications, basic spare parts inventory requirements are simplified and fewer spare parts are needed to support a plant-wide positioner applications base.

● With the cover removed, zero and span adjustments are easily accessible and can be made with a screw driver and spanner.

● Changes in supply pressure and valve load have minimal effect on positioner operation.

● Case, components, and gasket materials withstand harsh environments. Positioner bleed air purges internal parts for additional protection.

● Simple adjustments permit switching between direct and reverse action.

● To support diagnostic testing of valve/actuator/positioner packages with the FlowScanner™ valve diagnostic system, connectors, piping, and other hardware can be installed between the positioner and the actuator.

Specifications

Area Classification: Explosion Proof, Intrinsically Safe, Non-incendive, Dust

Certifications: CSA, FM, ATEX, IECEx, CUTR, Peso, KGS, INMETRO, NEPSI, RCM

Communication Protocol: 4-20mA Analog

Data Interface: Wired

Diagnostics: No

Input Signal: Electric

Mounting Type: Actuator Mounted

Operating Temperature: Standard Temperature, High Temperature

Position Control: Modulating

Process Control: Flow, Pressure, Temperature, Level

Safety Certifications: NIL

Supply Media: Air

Fisher™ 3582i electro-pneumatic positioner, accurate and fast-responding
