Pepperl+Fuchs KFU8-UFC-Ex1.D frequency converter with trip values. The device is a universal frequency converter that changes a digital input signal into a proportional free adjustable 0/4 mA ... 20 mA analog output signal and functions as a switch amplifier and a trip alarm. This isolated barrier is used for intrinsic safety applications.

The functions of the switch outputs (2 relay outputs and 1 potential free transistor output) are easily adjustable [trip value display (min/max alarm), serially switched output, pulse divider output, error signal output].

The device is easily configured by the use of keypad or with the PACTware configuration software. A fault is signalized by LEDs acc. to NAMUR NE44.

Features

● 1-channel isolated barrier

● Universal usage at different power supplies

● Input for NAMUR sensors or dry contacts

● Input frequency 1 mHz ... 5 kHz

● Current output 0/4 mA ... 20 mA

● Relay contact and transistor output

● Start-up override

● Line fault detection (LFD)

● Up to SIL 2 acc. to IEC 61508/IEC 61511

Associated

K-ADP-USB

KFD2-EB2

UPR-03

UPR-03-S

UPR-03-M

K-DUCT-BU

K-DUCT-BU-UPR-03
