Pepperl+Fuchs KFD2-STC4-Ex1.2O isolated barrier is used for intrinsic safety applications. The device supplies 2-wire and 3-wire SMART transmitters in a hazardous area, and can also be used with 2-wire SMART current sources. It transfers the analog input signal to the safe area as an isolated current value. Digital signals may be superimposed on the input signal in the hazardous or safe area and are transferred bi-directionally. If the HART communication resistance in the loop is too low, the internal resistance of 250 Ω between terminals 8 and 9 can be used. Test sockets for the connection of HART communicators are integrated into the terminals of the device.

Features:

1-channel isolated barrier

24 V DC supply (Power Rail)

Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources

Signal splitter (1 input and 2 outputs)

Dual output 0/4 mA ... 20 mA

Terminal blocks with test sockets

Up to SIL 3 acc. to IEC 61508

More models:

Pepperl+Fuchs SMART Transmitter Power Supply, Output Current Sink KFD2-STC4-Ex1.2O-Y1.

Pepperl+Fuchs SMART Transmitter Power Supply KFD2-STC4-Ex1.2O.H.

Associated Products: KFD2-STC4-Ex1.2O

KFD2-EB2 Power Feed Module

UPR-03 Universal Power Rail

UPR-03-M Universal Power Rail

UPR-03-S Universal Power Rail

K-DUCT-BU Profile Rail

K-DUCT-BU-UPR-03 Profile Rail
