MOXA EDS-205A-S-SC unmanaged ethernet switch with 4 10/100BaseT(X) ports, 1 100BaseFX single-mode port with SC connector, -10 to 60°C operating temperature.

The EDS-205A Series 5-port industrial Ethernet switches support IEEE 802.3 and IEEE 802.3u/x with 10/100M full/half-duplex, MDI/MDI-X autosensing. The EDS-205A Series has 12/24/48 VDC (9.6 to 60 VDC) redundant power inputs that can be connected simultaneously to live DC power sources. These switches have been designed for harsh industrial environments, such as in maritime (DNV/GL/LR/ABS/NK), rail wayside, highway, or mobile applications (EN 50121-4/NEMA TS2/e-Mark), or hazardous locations (Class I Div. 2, ATEX Zone 2) that comply with FCC, UL, and CE standards.

The EDS-205A switches are available with a standard operating temperature range from -10 to 60°C, or with a wide operating temperature range from -40 to 75°C. All models are subjected to a 100% burn-in test to ensure that they fulfill the special needs of industrial automation control applications.

Features and Benefits

• 10/100BaseT(X) (RJ45 connector), 100BaseFX (multi/single-mode, SC or ST connector)

• Redundant dual 12/24/48 VDC power inputs

• IP30 aluminum housing

• Rugged hardware design well suited for hazardous locations (Class 1 Div. 2/ ATEX Zone 2), transportation (NEMA TS2/EN 50121-4/e-Mark), and maritime environments (DNV/GL/LR/ABS/NK)

• -40 to 75°C operating temperature range (-T models)

MOXA EDS-205A Series 5-port unmanaged Ethernet switches:

EDS-205A, -10 to 60°C

EDS-205A-T, -40 to 75°C

EDS-205A-M-SC, -10 to 60°C

EDS-205A-M-SC-T, -40 to 75°C

EDS-205A-M-ST, -10 to 60°C

EDS-205A-M-ST-T, -40 to 75°C

EDS-205A-S-SC, -10 to 60°C

EDS-205A-S-SC-T, -40 to 75°C

Accessories:

DR-120-24, 120W/2.5A DIN-rail 24 VDC power supply with universal 88 to 132 VAC or 176 to 264 VAC input by switch, or 248 to 370 VDC input, -10 to 60°C operating temperature

DR-45-24, 45W/2A DIN-rail 24 VDC power supply with universal 85 to 264 VAC or 120 to 370 VDC input, -10 to 50°C operating temperature

DR-75-24, 75W/3.2A DIN-rail 24 VDC power supply with universal 85 to 264 VAC or 120 to 370 VDC input, -10 to 60°C operating temperature

MDR-40-24, DIN-rail 24 VDC power supply with 40W/1.7A, 85 to 264 VAC, or 120 to 370 VDC input, -20 to 70°C operating temperature

MDR-60-24, DIN-rail 24 VDC power supply with 60W/2.5A, 85 to 264 VAC, or 120 to 370 VDC input, -20 to 70°C operating temperature

Wall-Mounting Kits:

WK-30, Wall-mounting kit, 2 plates, 4 screws, 40 x 30 x 1 mm

WK-46, Wall-mounting kit, 2 plates, 8 screws, 46.5 x 66.8 x 1 mm
