Tektronix THS3014 100 MHz, 2.5 GS/s, rise time 3.5 ns, 1000 VRMS CAT II / 600 VRMS CAT III from BNC shell to earth ground, 4-channel handheld oscilloscope. With four isolated channels and up to seven hours of battery life, the lightweight THS3000 Handheld Oscilloscope Series enables you to safely make floating or differential measurements on your bench or in the field. Now you can tackle tough environments with the performance you expect from Tektronix - safely and affordably.

Key features
● 21 automatic measurements
● Waveform math and FFT spectral analysis
● Volts, time, frequency, watts cursor measurements
● Measurement data logging with TrendPlot™
● Waveform pass/fail limit testing
● Automatic 100 display screens recorder
● 6 in. (153 mm) bright color display
● USB device and host support, Maximum USB memory size supported is 2 GB
● 7 hours of continuous battery operation
Applications
● Embedded analog and digital design
● Power devices, power electronics, and power supply design
● Automotive and avionics design and maintenance
● Industrial equipment design and installation
● Field test and service

Tektronix THS3014 handheld oscilloscope
