Siemens 7MF4033-1EA10-2DB6-Z C14+E56 SITRANS P DS III / P410 pressure transmitter. SITRANS P DS III / P410, HART, 4-20 mA transmitter for pressure. Measuring cell filling silicone oil, normal cleaning Span: 0,63 ... 63 bar g (9.14 ... 914 psi g), overload limit 100 bar Diaphragm stainless steel, measuring cell stainless steel Process connection: female thread 1/2-14 npt Die-cast aluminium housing International design english inscription and documentation as cd Explosion protection EEx d cenelec) Electric connection and cable inlet: cable gland M20 x 1.5 Housing cover with window Factory certificate to DIN 50 049-2.2 / EN 10 204-2.2 Explosion-proof Ex d to NEPSI (China).

Siemens SITRANS P DS III digital pressure transmitter

Siemens 7MF4033-1EA10-2DB6-Z C14+E56 SITRANS P DS III / P410 pressure transmitter

The 2-wire transmitter SITRANS P DS III is a digital pressure transmitter for measuring gauge pressure, absolute pressure, differential pressure and flow as well as level.

● Measuring accuracy up to 0.065%

● Measuring range adjustment 100: 1

● Parameterization using:

- 3 buttons and HART for SITRANS P DS III HART

- 3 buttons and PROFIBUS PA for SITRANS P DS III PA

- 3 buttons and FOUNDATION Fieldbus for SITRANS P DS III FF

Our products are 100% New & Original, in stock, low price promotion.
If you can't find a suitable product model or require additional information, please contact us.
Click here to see more products →
