The Tektronix TBS1102B Digital Storage Oscilloscope Series provides you with affordable performance in a compact design. Packed with standard features - including USB connectivity, 34 automated measurements, limit testing, data logging, frequency counter, trend plot and a context-sensitive help menu - the Tektronix TBS1102B Oscilloscopes helps you get more done, in less time.

Product Features:

100 MHz bandwidth

2 channel

Up to 2 GS/s sample rate on all channels

2.5k point record length on all channels

Advanced triggers including pulse and line-selectable video triggers

34 automated measurements

Dual window FFT, simultaneously monitors both the time and frequency domains

Built-in waveform limit and trend plot testing

Dual channel frequency counter

Zoom Function

Automated, extended data logging feature

Autoset and auto-ranging functions

Built-in context-sensitive help

Multiple-language user interface

7 inch WVGA (800X480) Active TFT Color Display

Small footprint and lightweight - Only 4.9 in. (124 mm) deep and 4.4 lb.(2 kg)

5-year warranty

Connectivity

USB 2.0 host port on the front panel for quick and easy data storage

USB 2.0 device port on rear panel for easy connection to a PC

Applications

Industrial Automation Control, Hobby & Education, Industrial, Instrumentation, Test & Measurement, Research & Development, Consumer Electronics, Aerospace, Defence, Military, Electronics Design, Embedded Design & Development
